9. Technical data
9.1 Specifications
Table 11 Operating environment
Property Description/Value
Operating temperature 0 … +40 °C (+32 … +104 °F)
Storage temperature −20 … +80 °C (−4 … +176 °F)
Operating humidity 2 … 95 %RH, non-condensing
IP rating IP20
Flammability class UL94 V‑0
Table 12 Inputs and outputs
Property Description/Value
Supply voltage 12 … 28 VDC
Maximum power consumption at +20 °C (+68 °F) 15 W
Typical power consumption at +20 °C (+68 °F) 4 W
Data interfaces Ethernet (10/100 MBit/s), RS‑422, RS‑485, RS‑232
Service interface USB
Table 13 User interface
Property Description/Value
Display 5.7‑inch TFT LCD, 640 × 480 VGA resolution,
> 500 cd/m
2
luminance
Viewing angle Horizontal: −60° … +60°
Vertical: −60° (down) … +45° (up)
Brightness control Manual
User input interface Touch screen
Audible alarm > 80 dB(A) at 1 m (3 ft 3 in), 2 kHz
Table 14 Compliance
Property Description/Value
Directives EMC, LV, RoHS
WID511 User Guide M211109EN-L
88
