More information
‣
Entering Maintenance mode (basic settings) (page 43)
7.3 Exiting Maintenance mode (advanced
settings)
To exit the advanced Maintenance mode, press Home on any of the advanced settings
pages, or press Back on the Advanced settings page.
7.4 Buttons on Advanced settings page
The following table lists the buttons available on the Advanced settings page.
Table 8 Maintenance mode buttons (Advanced)
Button Description
Network Displays network information for the display (for example, the IP address).
Configurations Allows you to export the existing display configuration to a USB Flash memory stick
and to import a new configuration from a USB Flash memory stick to the display.
SW Update Displays the current software version.
For Vaisala use only: Allows upgrading to a newer software version to the display
using USB Flash memory.
Page selection Opens the page for selecting which of the available data pages are displayed.
Messages Opens the page for selecting which messages are in use.
Enables also configuring the message settings and the settings of the respective
sensor.
COM Opens the page for configuring the communication settings or viewing the data flow
when serial line connection is used for receiving sensor data.
NET Opens the page for configuring the communication settings or viewing the data flow
when Ethernet connection is used for receiving sensor data.
Station Opens the page for configuring the station settings.
Data settings Opens the page for selecting how the wind speed and wind direction data values are
displayed in the ATC layout.
Time settings Opens the page for setting the time manually or using Network Time Protocol (NTP)
server address.
Back On the Advanced settings page: Logs you out from advanced settings.
On other pages, returns to the previous page without saving changes ( = cancel).
Home Logs you out from advanced settings and returns to Observation mode.
Chapter 7 – Advanced settings in Maintenance mode
55
