Valleylab Force FX-8C - Page 141

Responding to System Alarms
Troubleshooting
Force FX-8C Service Manual 6-13
Number Description Recommended Action
112
113
114
115
116
117
118
119
Software malfunction. cal_mode value in
ca_clock_date_setup( ) outside state
range
Software malfunction. cal_state value in
ca_clock_time_setup( ) outside state
range
Software malfunction. cal_mode value in
ca_clock_time_setup( ) outside state
range
Software malfunction. cal_state value in
ca_coag_leakage_cal( ) outside state
range
Software malfunction. cal_state value in
ca_econ_cal( ) outside state range
Software malfunction. econ_cal_state
value outside state range
Software malfunction. cal_state value in
ca_rem_cal( ) outside state range
Software malfunction. rem_cal_state value
outside state range
Turn off, then turn on the generator. If the alarm number
reappears, record the number and call the Valleylab Service
Center.
120 Calibration malfunction. Calibration
value(s) outside acceptable range
Repeat the failing calibration step. If the alarm number reappears,
record the number and call the Valleylab Service Center.
121 Software malfunction. cal_mode value in
ca_generator_setup( ) outside state range
Turn off, then turn on the generator. If the alarm number
reappears, record the number and call the Valleylab Service
Center.
122 Open circuit REM sense failure Repeat the failing calibration step. If the alarm number reappears,
record the number and call the Valleylab Service Center.
123
124
125
126
Main microcontroller unable to access
GEN_SEM semaphore
Main microcontroller unable to access
FEEDBACK_SEM semaphore
Main microcontroller unable to access
ECON_SEM semaphore
Main microcontroller unable to access
KEY_ACTIVE_SEM semaphore
Refer to Correcting IC U6 Malfunctions in this section.
151 Main microcontroller unable to access
GEN_SEM semaphore
Refer to Correcting IC U6 Malfunctions in this section.
152 Software malfunction. cal_state value in
cs_i_sns_cal( ) outside state range
Turn off, then turn on the generator. If the alarm number
reappears, record the number and call the Valleylab Service
Center.
