Van's Aircraft RV-12 Maintenance Manual

Rev. 2
7-4
DISCONNECTION
1. Drain the hydraulic fluid. (7-5)
2. Make note of the hose connections.
3. Disconnect brake lines from master cylinder.
INSTALLATION
1. Installation procedure is reverse of the removal procedure.
2. Bleed the brake system. (7-5)
SERVICE SCHEDULE PROCEDURES
BRAKE PEDAL TORQUE TUBE LUBRICATION
Tools
7/16 socket
7/16 combo wrench
Needle nose pliers
Expendable
Cotter pins
Wheel bearing grease
Replaceable
None
Service Rating
Line
Minimum Certification
LSA-RM, or A&P
Additional References
KAI
●
NOTE:
S
ERVICE ONE PEDAL AT A TIME
.
1. Actuate the rudder
pedals so that the
brake pedal to be
serviced is offset
from the adjacent
rudder and brake
pedal. The
following steps
relate to Figure 19.
2. Remove the
master cylinder
lower hardware.
3. Remove the brake
pedal hardware;
bolt, washer, and
nut.
Figure 19: Torque tube lubrication
