Van's Aircraft RV-12 Maintenance Manual

Rev. 6
5-9
COMPONENTS
Quantity
Part or Assembly Name
Part Number or Reference
1
Left Main Gear
U-1220-L
1
Right Main Gear
U-1220-R
2
Outbd Main Gear Attach Brkt
U-1202
2
Outbd Doubler Plate
U-1202C
2
Outbd Wear Plate
U-1202D
2
Inbd Main Gear Attach Brkt
U-1203
2
Inbd Wear Plate
U-1203B
2
Doubler Plate
U-1203C
2
Inbd Doubler Plate
2
Main wheel assembly
See shaded items below
1
Main wheel
U-MHMHE51B
2
Wheel bearings
BEARING LM-67000L-A
1
Axle
MHE51B AXLE
1
Nose gear
WD-1201
1
Nose fork
WD-1230-1
1
Nose wheel assembly
See shaded items below
1
Nose wheel
U-WHLNW51CC.625
1
Axle
U-1210A-1
2
Spacer
U-1210B-1
4
Wave washer
5806-148-3
1
Wheel bearing
N/A
3
Tire
U 5.00 X 5 TIRE
3
Tube
U 5:00X5-6IT
