Van's Aircraft RV-12 Maintenance Manual

Rev. 6
5-19
■
CAUTION:
U
PPER AND LOWER RUDDER HINGES ARE NOT INTERCHANGABLE
.
4. Install the new rudder hinge and hardware.
5. Install the rudder assembly.
6. Install the upper and lower tailcone fairing.
STABILATOR HINGE REPLACEMENT
Tools
1/4 drive socket slightly less than
5/8in in diameter. A common
standard 7/16 socket generally
works.
3/8 drive 3/4 socket
Screwdriver
3/8 Wrench
7/16 socket, ratchet and
extension
Needle nose pliers
Hex Bolt 1/4 diameter 3 inches
long (must be threaded at least
50% of its length)
1/4 Flat Washer(2) and Hex Nut
Expendable
Cotter pins
Lock Clips (2)
Loctite 648
Replaceable
Bearing DW4K2X
Service Rating
Line
Minimum Certification
LSA-RM or A&P
Additional
References
KAI
■
CAUTION:
B
E PREPARED WITH ADDITIONAL PERSONEL OR TOOLS TO HANDLE THE
WEIGHT AND AWKWARDNESS OF THE OBJECT TO BE REMOVED.
Removing the Stabilator
1. Remove the upper and lower tailcone fairing. (3-4)
●
NOTE:
B
EFORE DISCONNECTING THE STABILATOR CONTROL CABLES BE
PREPARED TO PREVENT THE ENDS OF THE CABLES FROM FALLING INTO THE
TAILCONE.
2. Remove the two aft most belly inspection covers.
