Rev. 6
5-22
O NOT REMOVE THE UPPER VIBRATION
ISOLATOR BOLTS
3. Remove the lower engine vibration-isolator bolts (2).
4. Remove the nose gear-leg hardware from the fuselage; bolts (13) and washers
(13).
HE ENGINE CAN BE LIFTED BY HAND AT THE GEARBOX
5. Lift the front of the engine only enough to remove the engine weight from the
gear-leg bracket.
6. Remove the nose gear-leg.
INSTALLATION
1. Lift the front of the engine only enough to provide room behind the engine mount
for the nose gear-leg.
2. Install the nose gear-leg and attach hardware.
3. Install the lower engine vibration isolator bolts.
BELT AND HARNESS REPLACEMENT
7/16 socket
7/16 combo wrench
Owner and SPC, LSA-
RM, or A&P
ARNESS PARTS THAT SHOW ANY SIGN OF WEAR REQUIRE THAT THE
ENTIRE HARNESS SET BE REPLACED IMMEDIATELY.
1. Remove the seat ramp cover. (3-4)
2. Remove the crotch strap; bolt, bushing, washer, nut.
3. Remove each waist strap (2); bolt, bushing, washer, nut.
4. Remove the shoulder straps; bolt, bushing, washer, nut.
5. Install the new harness set and attach hardware.
