SPT
Account
Code
The number that uniquely identifies the panel to the RCT. Enter 0 if you do not have the SPT
Account Code. In this case, you can commission the panel using the ATS Registration ID. For an
EN50136 ATS, the ATS Registration ID is automatically generated when you click Save. The
RCT can send the SPT Account Code to the panel when it is available.
RCT Identification & Backup RCT Identification (Dual Path Dual Server Only)
RCT ID Enter the RCT ID that uniquely identifies the RCT (for example, SPC Com XT) to the panel. This
must match the value entered in the SPC Com XT Server Configuration Manager tool in the Server
RCT ID field in the Server Details tab. See the SPC Com XT Installation & Configuration Manual.
RCT URL
or IP
Address
Enter the RCT URL or IP Address for the RCT server location (for example, SPC Com XT
server).
RCT TCP
Port
Enter the TCP port for the RCT (for example, SPC Com XT). This must be the same value entered
for the field Server FlexC Port in the SPC Com XT Server Configuration Manager tool.
ATP Interface
EN50136
ATS
Category
Select the EN50136 ATS Category (SP1-SP6, DP1-DP4). For a description of categories, see
ATS Category Timings on page397.
Primary
Interface
Select the Primary Interface to apply to the primary communications path from the following:
l Ethernet
l GPRS: Modem 1
l GPRS: Modem 2
l Dial Up Internet: Modem 1
l Dial Up Internet: Modem 2
Backup
Interface
For a Dual Path ATS, select the Backup Interface to use for the backup communications path
from the following:
l Ethernet
l GPRS: Modem 1
l GPRS: Modem 2
l Dial Up Internet: Modem 1
l Dial Up Internet: Modem 2
17.11.2.3 Configuring an EN50136-1 ATS or Custom ATS
An ATS comprises an alarm panel, network paths and an RCT (for example, SPC Com XT). It combines
one or multiple paths between an SPC panel and an RCT. You can add up to 10 ATPs to an ATS.
NOTICE:For an EN50136-1 ATS, the ATS set up sequence starts with configuring an ATP for an
ATS. This provides you with a quick set up feature. See Quick Start ATP Configuration for EN50136
ATS on page305.
1. To configure an ATS, go to Communications > FlexC > FlexC ATS.
2. Choose from one of the following options:
l Add Single Path ATS
l Add Dual Path ATS
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 307 A6V10276959-d
11.2018
