C
HAPTER
3. M
AINTENANCE
P
ROCEDURES
3-99
02.9628.0010 CONFIDENTIAL
7-Oct-97
Step 8. Prepare and install replacement input connector.
a. At replacement receptacle, insert five 22 AWG wires and
three 18 AWG wires using the following pinouts:
Pin Wire Wire Size Description
1 N/C
2 RED 22 AWG BRDCST +
3 GRN 22 AWG DATA GND
4 BLK 22 AWG BRDCST -
5 GRY 22 AWG REPLY -
6 WHT 22 AWG REPLY +
7 WHT 18 AWG NEUTRAL
8 GRN 18 AWG GROUND
9 BLK 18 AWG AC
b. Complete receptacle replacement by doing Steps 2 thru 7 in
reverse.
