CONFIDENTIAL 02.9628.0010
7-Oct-97
4.2.2.3 Assy, Blue/Amber Bulkhead ( VL4 )
22.4006.0001
NO. PART NO. QTY DESCRIPTION
1 10.9620.0063 6 EA CARRIER, FILTER
2 10.9620.0245 6 EA BUSHING, FILTER CARRIER
3 10.9620.0246 6 EA BUSHING, FILTER GEAR
4 10.9628.0018 1 EA MOUNT, MOTOR
5 10.9628.0019 6 EA GEAR, FILTER
6 10.9628.0069 1 EA REFLECTOR, VL4
7 10.9628.0080 12 EA PAD, FILTER
8 10.9628.0085 1 EA MOUNT, REFLECTOR
9 22.5016.0001 2 EA ASSY, 15 DEGREE STEPPER MOTOR
10.9620.0161 1 EA WORM, STAINLESS STEEL, 1/8” BORE
44.5016.0001 1 EA MOTOR, STPR 15DEG CAN-STACK 25OH COIL
55.6677.0002 1 EA WASHER, .360OD X .123ID X .025THK, NYLON
10 22.9628.0011 1 EA ASSY, VL4 COLOR CHANGER BULKHEAD
11 22.9628.0247 2 EA ASSY, FILTER GEAR DRIVE - VL4
10.9628.0019 1 EA GEAR, FILTER
10.9628.0107 1 EA SHAFT, EXTENSION, FILTER GEAR
12 41.9628.0136 2 EA FILTER, LWP, 4 1/8" X 1 11/16" (VL4)
13 41.9628.0137 1 EA FILTER, LWP, 4 1/8" X 2"
14 41.9628.0138 2 EA FILTER, SWP, 4 1/8" X 1 11/16" (VL4)
15 41.9628.0139 1 EA FILTER, SWP, 4 1/8" X 2" (VL4)
16 52.6300.0001 2 EA CONN HOUSNG, MTA CLOSED END NATRL 4PIN
17 52.6383.0001 2 EA CONN HOUSING MTA CLOSED END BLU 8PIN
18 52.6424.0004 2 EA COVER, STRAIN RELIEF/4POS MTA
19 52.6424.0008 2 EA COVER, STRAIN RELIEF/8POS MTA
20 53.2002.0001 4 EA NUT, 6-32 KEP ZINC PLATED
21 53.2003.0001 4 EA NUT, 4-40, KEP ZINC PLATED
22 53.2009.0003 4 EA NUT, 2-56 NYLON INSERT STOP LOCKING
23 53.2301.0001 12 EA PALNUT, 1/2-13 UNC THRD. X 3/4 OD
24 53.6534.0001 4 EA RIVET, POP, ALUM 3/32OD,3/32GRIP RANGE
25 53.6557.0001 4 EA SCREW, 6-32 X 9/16"PPZ
26 53.6597.0001 4 EA SCREW, 4-40 X 3/16” PPZ
27 54.1208.0001 2 EA BEARING, 1/4”
28 55.2123.0002 6 EA WAVE SPRING
29 55.2179.0002 2 EA SADDLE, TYWRAP (VL-1)
30 55.2198.0001 2 IN HEAT SHRINK 1/8” BLK
31 55.6510.0001 1 IN GROMMET, 032-.052THK .052ID
