4-14
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
4.2.2.5 Assy, Diffuser Mechanism (
VL4
)
22.4003.0001
NO. PART NO. QTY DESCRIPTION
1 10.9628.0063 1 EA TRACK, DIFFUSER, TOP
2 10.9628.0064 1 EA TRACK, DIFFUSER, BOTTOM
3 10.9628.0075 2 EA PULLEY, IDLER
4 10.9628.0076 2 EA PULLEY, REDUCTION
5 10.9628.0099 4 EA PIN, ACTUATOR, DIFFUSER
6 10.9628.0104 1 EA SHAFT, DRIVE, DIFFUSER
7 10.9628.0110 1 EA MOUNT, MOTOR, DIFFUSER
8 10.9628.0141 1 EA FILTER, ULTRA-VIOLET, 4.062" SQUARE
9 10.9628.0189 1 EA PULLEY, DRIVE, DIFFUSER
10 10.9628.0208 2 EA STANDOFF, SPECIAL, RND, 2-56X3/16X4 9/16
11 10.9628.0224 1 EA PLATE, SPACER, UV GLASS/DIFFUSER
12 10.9628.0228 2 EA SCREW, SHOULDER, ECCENTRIC
13 10.9628.0230 20 EA CARRIER, DIFFUSER, (VALOX)
14 12.4003.0001 4 EA GLASS PANEL, MACHINED, GLARE RES.CLEAR
15 12.4003.0002 4 EA GLASS PANEL, MACHINED, PATTERN #62
16 12.4003.0003 2 EA GLASS PANEL, MACHINED, MOSS PATTERN
17 22.9628.0092 1 EA ASSY, VL4 DIFFUSER FRNT APERTURE PLATE
18 44.5001.0000 1 EA MOTOR, STEPPER 7.5DEG 25 OHM COIL
19 52.6300.0001 1 EA CONN HOUSING, MTA CLOSED END Natrl 4PIN
20 52.6383.0001 1 EA CONN HOUSING, MTA CLOSED END BLU 8PIN
21 52.6424.0004 1 EA COVER, STRAIN RELIEF/4POS MTA
22 52.6424.0008 1 EA COVER, STRAIN RELIEF/8POS MTA
23 53.2002.0001 2 EA NUT, 6-32, KEP ZINC PLATED
24 53.2003.0001 2 EA NUT, 4-40, KEP ZINC PLATED
25 53.2009.0003 2 EA NUT, 2-56 NYLON INSERT STOP LOCKING
26 53.6559.0002 4 EA SCREW, 4-40 X 1/4"PFB
27 53.6659.0005 4 EA SCREW, 2-56x1/4"PFZ
28 54.2001.0004 2 EA BELT, DIFF(LONG),VL4,.0816P,150T,.187W
29 54.2002.0002 2 EA BEARING, 1/8"BORE S/S ROLLER
30 54.2002.0003 4 EA RING, RETAINING EXTERNAL 3/16"ID
31 54.2002.0004 4 EA RING, RETAINING E-RING 1/8"ID
32 54.2002.0005 1 EA BELT, DIFF(SHORT),VL4,.0816P,81T,.187W
33 55.2111.0001 2 EA WASHER, S/S FLAT,.437OD X .159ID X.028THK
34 55.2178.0001 1 EA CABLE ANCHOR MOUNT, #8 SCREW MOUNTING
35 55.2186.0001 1 EA CABLE TIE, SMALL .10X4”
36 55.2198.0001 1 IN HEATSHRINK 1/8" BLK
37 55.2203.0001 2 EA SCREW, 4-40X1/4” PPZ
