VARILITE VL4 - Page 169

C
HAPTER
4. I
LLUSTRATED
P
ARTS
B
REAKDOWN
4-15
02.9628.0010 CONFIDENTIAL
7-Oct-97
Assy, Diffuser Mechanism ( VL4 ) (continued)
22.4003.0001
NO. PART NO. QTY DESCRIPTION
38 55.6621.0001 2 EA WASHER, FLAT #4 ID .120 .028THK
39 55.6677.0002 3 EA WASHER, .360OD X .123ID X .025THK,NYLON
40 73.7021.0006 23 IN WIRE, 24AWG BLUE TWISTED PR.
41 74.1023.0001 1 EA SWITCH, GOLD CROSSPOINT CONTACT
1
30319,393218
6
15
14
2
3031
14
11
8
17
21
19
734,352022 36,40,41
26
24
37
38
45
27
13
29
23 25
10
333
12
16
(1 PL)
28
16
(1 PL)
15
4
3
