4.2.2.6 Assy, Yoke Rails & Covers ( VL4 )
22.4002.0001
NO. PART NO. QTY DESCRIPTION
1 10.9628.0042 1 EA COVER, REAR
2 10.9628.0119 1 EA COVER, SIDE, CABLE
3 10.9628.0120 1 EA COVER, TILT MECHANISM
4 10.9628.0123 1 EA PLATE, STOP, PAN
5 10.9628.0124 1 EA STOP, VL4 PAN
6 10.9628.0210 1 EA STABILIZER, PAN
7 10.9628.0211 1 EA STABILIZER, PAN/TILT
8 10.9628.0212 1 EA BRACKET, STABILIZER, PAN
9 10.9628.0213 2 EA FLANGE, PULLEY, TILT
10 10.9628.0236 1 EA COUNTERWEIGHT, VL4
11 22.4001.0001 1 EA ASSY, PAN DRIVE (VL4)
12 22.4004.0001 1 EA ASSY, TILT MECHANISM (VL4)
13 22.9628.0033 1 EA ASSY, VL4 YOKE
14 22.9628.0039 1 EA ASSY, VL4 PULLEY SIDE RAIL
10.9628.0039 1 EA RAIL, SIDE, PULLEY
53.6506.0001 1 EA BEARING, TORQUE TUBE, 2.6250OD X 2.0620ID
54.1206.0001 1 EA RING, RETAINING 2.521” ID
15 22.9628.0040 1 EA ASSY, VL4 CABLE SIDE RAIL
10.9628.0040 1 EA RAIL, SIDE, CABLE
53.6506.0001 1 EA BEARING, TORQUE TUBE, 2.6250OD X 2.0620ID
54.1206.0001 1 EA RING, RETAINING 2.521” ID
16 22.9628.0057 1 EA ASSY, VL4 YOKE BEARING FRAME
17 22.9628.0118 1 EA COVER, VL4 PULLEY SIDE
18 22.9628.0177 1 EA ASSY, CONNECTORIZED FAN
19 24.9628.0049 1 EA PCB ASSY, VL4 YOKE CABLE TERM (YTB)
20 24.9628.0096 1 EA PCB ASSY, VL4 IGNITOR (IGN4)
21 25.9628.0145 1 EA CABLE ASSY, YOKE "A" 38" (VL4)
22 25.9628.0147 1 EA CABLE ASSY, YOKE "B" 41" (VL4)
23 25.9628.0149 1 EA LAMP WIRE ASSY, A & B (VL4)
24 53.2001.0001 5 EA NUT, 10-32, KEPS ZINC PLATED
25 53.2001.0003 3 EA NUT, 10-32 NYLON INSERT
26 53.2002.0001 3 EA NUT, 6-32 KEP ZINC PLATED
27 53.2002.0003 3 EA NUT, 6-32 HEX Z NY INSERT
28 53.2003.0001 2 EA NUT, 4-40, KEP ZINC PLATED
29 53.6517.0001 3 EA SCREW, 10-32 X 3/8"PPZ
30 53.6524.0002 29 EA SCREW, 6-32X5/16"PPB
31 53.6538.0001 1 EA SCREW, 10-32X7/8"PPB
32 53.6559.0001 2 EA SCREW, 4-40X1/4"PFZ
33 53.6593.0001 1 EA SCREW, 10-32X1"PPB
