Assy, Yoke Rails & Covers ( VL4 ) (continued)
22.4002.0001
NO. PART NO. QTY DESCRIPTION
34 53.6594.0001 3 EA SCREW, 10-32X1-1/2"PPB
35 53.6608.0001 3 EA SCREW, 6-32X3/8"PFB
36 53.6612.0001 1 EA SCREW, 6-32X1/2"PPB
37 53.6621.0001 1 EA SCREW, 8-32X1"PPB
38 54.1205.0001 1 EA RING, RETAINING 1.963" ID
39 54.2001.0003 1 EA BELT, PAN, VL4 1/5P, 65T, .375W KEVLAR
40 55.2102.0001 4 EA CARD GUIDE, NYLON 4"
41 55.2114.0001 3 EA WSHER, LCK INT TTH #10
42 55.2124.0001 1 EA SPRING, CURVE (HIGH CARBON)
43 55.2129.0002 2 EA SHIM, STAINLESS STEEL, PAN TUBE
44 55.2178.0001 1 EA CABLE ANCHOR MOUNT, #8 SCREW MOUNTING
45 55.2201.0001 1 EA SCREW, 4-40 X 5/16” PFB
46 55.6517.0001 1 EA WASHER, FLAT STEEL .375ODx.150IDx.031THK
47 55.6522.0001 3 EA WASHER, FLAT, .750 OD, .192 ID
48 55.6528.0001 3 EA WASHER, FLAT #6 ZINC
49 55.6568.0015 3 EA SPRING, COMP.,1.25FL X .455 OD S/S
50 55.6568.0016 1 EA SPRING, EXTENSION, 1/2"FL X 1/8"OD
51 55.6580.0002 1 EA TIE, CABLE .18X8"
52 55.6599.0001 2 EA WASHER, FLAT BLACK #10
53 55.6623.0001 3 EA WASHER, FLAT #10
54 55.6662.0001 1 EA HOLE PLUG 3/4"BRASS W/BLK OXIDE
55 55.6669.0006 3 EA STANDOFF, 5/16"HEX 10-32x1"MF STEEL
56 55.6677.0004 4 EA WASHER, NYLON, .375"ODx.125"IDx.062"Thk
