4.2.2.9 Assy, Tilt Mechanism ( VL4 )
22.4004.0001
NO. PART NO. QTY DESCRIPTION
1 10.9620.0005 1 EA WHEEL, WORM, REDUCTION, PAN/TILT
2 10.9620.0107 1 EA MOUNT, MOTOR, PAN/TILT
3 10.9620.0270 1 EA SEAL, ENCODER
4 10.9620.0293 1 EA PAD, ANTI-BACKLASH, PTA
5 10.9628.0116 1 EA MOUNT, ENCODER, TILT
6 10.9628.0117 1 EA SPACER, ADJUSTMENT, BACKLASH, TILT
7 10.9628.0143 3 EA STANDOFF, SPECIAL, RND, 6-32X5/16X.187
8 10.9628.0144 1 EA STANDOFF, SPECIAL, SQR, TILT MECHANISM
9 10.9634.0051 1 EA WASHER,"D", PTA
10 22.5007.0001 1 EA ASSY, MAXON MOTOR
11 22.9628.0115 1 EA ASSY, VL4 TILT BOTTOM PLATE
12 22.9628.0220 1 EA ASSY, DRIVE SHAFT - PAN & TILT
13 45.5101.0001 1 EA ENCODER 256 COUNT
14 52.6270.0001 1 EA CONN HOUSING, MTA CLOSED END RED 5PIN
15 52.6300.0001 1 EA CONN HOUSING, MTA CLOSED END Natrl 4PIN
16 52.6424.0004 1 EA COVER, STRAIN RELIEF/4POS MTA
17 52.6424.0005 1 EA COVER, STRAIN RELIEF/5POS MTA
18 53.2001.0001 1 EA NUT, 10-32, KEPS ZINC PLATED
19 53.6513.0001 3 EA SCREW, 2.5MM X 4MM
20 53.6515.0001 1 EA SCREW, 10-32X3/4 SCB CAP
21 53.6522.0001 3 EA SCREW, 6-32X1/4"PPZ
22 53.6591.0001 5 EA SCREW, 6-32X1/4"PFZ
23 53.6592.0002 3 EA SCREW, 4-40X1/2"SCB
24 54.1208.0001 2 EA BEARING, 1/4"
25 54.1222.0002 1 EA RING,RETAIN.,METRIC,FOR 9MM SHAFT
26 54.2004.0001 1 EA BELT,TILT,VL4,1/5P,70T,.290W,KEVLAR
27 55.2110.0002 1 EA WSHR, FLT STN ST.260ID.400OD.010THK
28 55.2123.0001 1 EA SPRING, WAVE 1/4"
29 55.2128.0001 7 EA SPRING, DISC, CLUTCH, VL5
30 55.2186.0001 2 EA CABLE TIE, SMALL .10X4”
31 55.2197.0001 2 IN HEAT SHRINK 3/8” BLACK
32 55.6526.0001 1 EA GROMMET, 1/4"BORE 1/2"O.D/3/8"HOLE 1/16"
33 55.6538.0001 3 EA WASHER, LOCK, #6 INTERNAL TOOTH
34 55.6677.0007 1 EA WASHER, FLAT,.75OD X.383ID X.031TH-BLKOX
35 55.6677.0008 1 EA WASHER, FLAT,S/S,.875OD X .3781
