VARILITE VL4 - Page 191

C
HAPTER
4. I
LLUSTRATED
P
ARTS
B
REAKDOWN
4-37
02.9628.0010 CONFIDENTIAL
7-Oct-97
4.2.3.6 Assy, Connectorized Transformer ( VL4 )
23.9628.0159
NO. PART NO. QTY DESCRIPTION
1 52.6319.0001 1 EA PLUG HOUSING, MNLOK 4POS
2 52.8244.0002 5 EA FASTON RECEPT FLAG,.250 16-14AWG (LOOSE)
3 52.8258.0001 4 EA CONTACT PIN, 20-14AWG MNLOK (LOOSE)
4 68.4518.0004 1 EA TRANSFORMER, VL4 110/220V LAMP UNIT
2
4
13
