VARILITE VL4 - Page 196

4-42
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
4.2.3.10 PCB Assy, VL4 Low Voltage Supply (LVS)
24.9628.0045
NO. PART NO. QTY REF DES DESCRIPTION
1 10.9628.0074 1 EA HEATSINK, LOW VOLT SUPPLY
2 11.9628.0046 1 EA PCB, VL4 LOW VOLTAGE SUPPLY
3 50.2708.0001 1 EA XU1 SOCKET, 8PIN DIP
4 51.5001.0001 5 EA AP: REG1.5 HEATSINK, TO-220 1" W/PINS
5 51.5003.0001 4 EA XQ1.3, XREG6 SOCKET, TO-3 PC/HEATSINK
6 51.5005.0001 4 EA AP:Q1.3, REG6 INSULATOR, TO-3
7 51.5006.0001 9 EA AP: REG1.5, Q6, 7, 10, 11 INSULATOR, TO-220
8 52.6246.0002 1 EA P1 CONN, 64PIN TYPE C RT W/MFBL PIN
9 53.2003.0001 9 EA AP: REG4, Q6, 7,
10, 11, HEATSINK
NUT, 4-40, KEP ZINC PLATED
10 53.2009.0003 2 EA NUT, 2-56 NYLON INSERT STOP LOCKING
11 53.6520.0001 5 EA AP: HEATSINK TO.220
REG1.5, Q6, 7, 10, 11
SCREW, 4-40X3/8"PPZ
12 53.6556.0001 4 EA HEATSINK SCREW, 4-40X3/4"PPZ
13 53.6613.0001 8 EA AP: Q1.3, REG6 SCREW, 6-32X1/2"PPZ
14 53.6659.0004 2 EA SCREW, 2-56X1/2"PPZ
15 55.2127.0001 4 EA AP: LVS HEATSINK STANDOFF, 3/16"HEX 4-40X3/8"
16 55.2188.0001 1 EA CABLE TIE, BLACK, .18 X 12"
17 55.6509.0001 5 EA AP: REG1.5 WASHER, SHOULDER (HEATSINK)
18 80.1612.5759 1 EA Q3 TRANSISTOR, 2N5759 NPN 120V 6A TO3
19 80.1613.6227 2 EA Q1, 2 TRANSISTOR, MJ15016 PNP 120V 15A TO3
20 83.3107.0001 1 EA REG6 IC, MPC100 +5V 5A VOLT.REGULATOR
60.1221.1301 2 EA R7, 13 RES, 1/4W 1% 1.30K CF
60.1223.1787 2 EA R5, 11 RES, 1/4W 1% 1.78K CF
60.1225.1186 4 EA R4, 6, 10, 12 RES, 1/4W 1% 118 CF
60.1424.1005 6 EA R14.16, 22.24 RES, 1/4W 5% 10K CF
60.2410.1000 4 EA R20, 21, 28, 29 RES, 1/2W 5% 1 OHM CC
60.2423.1007 2 EA R3, 9 RES, 1/2W 5% 10 OHM
60.2424.4702 4 EA R17, 19, 25, 27 RES, 1/2W 5% 470 CF
60.2431.1001 2 EA R18, 26 RES, 1/2W 5% 1.0K CF
60.7440.0015 2 EA R1, 2 RES, 5W 5% .15 OHM WW
60.7441.0033 1 EA R8 RES, 5W 5% .33 WW
62.2014.0104 2 EA C10, 11 CAP, .1UF, 50V,RAD,CERAMIC, .100",20%
62.2017.0105 6 EA C2, 5.7, 12, 13 CAP, 1.0UF, 50V,RAD,TANTALM, .125",10%
62.2023.0220 3 EA C1, 3, 4 CAP, 220UF, 35V,RAD,ALUMNUM, .197",20%
62.2027.0475 2 EA C8, 9 CAP, 4.7UF, 35V,RAD,TANTALM, .125",10%
80.1512.6122 2 EA Q7, 11 TRANSISTOR, 2N6122 NPN 60V 4A TO220
80.1513.6125 2 EA Q6, 10 TRANSISTOR, 2N6125 PNP 60V 4A TO220
80.2513.0005 2 EA Q4, 8 TRANSISTOR, MPSA05 NPN 60V 500MA TO92
80.2513.0055 2 EA Q5. 9 TRANSISTOR, MPSA55 PNP 60V 500MA TO92
