VARILITE VL4 - Page 200

4-46
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
4.2.3.13 Elec. Assy, VL4 Lamp Control (UCB/IFB)
23.9628.0232
NO. PART NO. QTY DESCRIPTION
1 10.9628.0190 1 EA BRACKET, HANDLE, UCB
2 24.9628.0073 1 EA PCB ASSY, VL4 UNIVERSAL CONTROL (UCB)
3 24.9628.0082 1 EA PCB ASSY, VL4 INTERFACE (IFB)
4 53.2004.0001 1 EA NUT, 8-32, KEP
5 53.6545.0004 1 EA SCREW, 8-32X3/8"PPZ
6 53.6659.0003 4 EA SCREW, 2-56X3/8"PPZ
7 53.6659.0004 4 EA SCREW, 2-56X1/2"PPZ
8 55.2188.0000 1 EA CLAMP, CABLE, BLK, .75DIA X .50WIDE
9 55.6677.0002 2 EA WASHER, .360OD X .123ID X .025THK,NYLON
10 55.6694.0001 2 EA STANDOFF, 5/32"RND 2.56X7/16
11 55.6694.0002 2 EA STANDOFF, 5/32"HEX 2.56X21/32
6
(2 PL)
7
(2 PL)
3
11
2
7
(2 PL)
5
8
1
4
6
(2 PL)
10
9
