C
HAPTER
4. I
LLUSTRATED
P
ARTS
B
REAKDOWN
4-47
02.9628.0010 CONFIDENTIAL
7-Oct-97
4.2.3.14 PCB Assy,
VL4
Universal Control (UCB)
24.9628.0073
NO. PART NO. QTY REF DES DESCRIPTION
1 11.9628.0070 1 EA PCB, UNIVERSAL CONTROL BOARD (UCB)
2 50.2714.0003 1 EA XLD1 SOCKET, 14PIN RT ANGLE 90DEG
3 52.6246.0002 1 EA P1 CONN, 64PIN TYPE C RT W/MFBL PIN
4 52.6422.0096 1 EA P2 CONN, EURO 96POS TYPE C FMLE STRGHT
5 65.5001.0001 1 EA B1 BATTERY, 3.6V LITHIUM SZ AA
6 74.1025.0001 3 EA SW1A, 1B, 1C SWITCH, SUBMINI P.WHL RT ANGLE
7 88.8115.0001 1 EA LD1 DISP, LED, COMMON ANODE LFT HAND
DECI.
50.2704.0001 2 EA XU3. 6 SOCKET, XTAL OSC, PC MT W/4 CONTACTS
50.2708.0001 1 EA XU10 SOCKET, 8PIN DIP
50.2714.0001 18 EA XU1, 2, 4, 8, 11, 32, 35, 36,
38, 41,
44, 47, 50, 52, 67, 69, 70,
73
SOCKET, 14PIN DIP
50.2716.0001 11 EA XU5,, 7, 33, 45, 48, 53, 54,
61, 65, 68, XRP27
SOCKET, 16PIN DIP
50.2720.0001 22 EA XU9, 34, 37, 39, 40, 42, 43,
46, 49,
51, 55.60, 62.64, 66, 71, 72
SOCKET, 20PIN DIP
52.6419.0014 20 EA XU13, 14, 17.20, 25, 26, 30,
31
SOCKET STRIP, 14POS ELEVATED
52.6419.0024 6 EA XU12, 28, 29 SOCKET STRIP, 24POS ELEVATED
52.6419.0032 6 EA XU15, 16, 27 SOCKET STRIP, 32POS ELEVATED
52.8284.0001 7 EA J1.7 TERM STRIP, 2.PIN STRAIGHT GOLD
CONTACT
52.8284.0002 2 EA J8, 9 TERM STRIP, DBL ROW RT ANGLE
52.8285.0001 5 EA J1, 3, 6, 7, 9 CONTACT, GOLD MICROSHUNT .260 HEIGHT
53.6659.0003 4 EA SCREW, 2-56X3/8"PPZ
60.1421.2701 1 EA R12 RES, 1/4W 5% 2.7M CF
60.1421.4701 1 EA R13 RES, 1/4W 5% 4.7K CF
60.1422.1001 2 EA R10, 14 RES, 1/4W 5% 1K CF
60.1423.1004 1 EA R11 RES, 1/4W 5% 1MEG CF
60.1424.1005 3 EA R1, 2, 15 RES, 1/4W 5% 10K CF
60.1431.1007 7 EA R3.9 RES, 1/4W 5% 10 OHM
61.4116.0472 1 EA RP27 RES DIP, 472 16PIN ISOLATED
61.4306.0102 1 EA RP8 RES SIP, 102 6PIN BUSSED LW PRFLE
61.4306.0103 5 EA RP2, 7, 14, 15, 25 RES SIP, 103 6PIN BUSSED LW PROFILE
61.4306.0470 1 EA RP1 RES SIP, 470 6PIN BUSSED LW PRFLE
61.4308.0102 4 EA RP3, 5, 6, 19 RES SIP, 102 8PIN BUSSED LW PRFLE
61.4310.0102 1 EA RP20 RES SIP, 102 10PIN BUSSED LW PRFLE
61.4310.0103 13 EA RP4, 9.13, 16. 17. 21.24, 26 RES SIP, 103 10PIN BUSSED
61.4608.0103 1 EA RP18 RES SIP, 103 8PIN BUSSED LW PRFLE
62.2015.0104 42 EA C1.9, 13.33, 35.46 CAP, .1UF, 50V,SIP,CERAMIC, .100",20%
62.2033.0476 2 EA C11, 12 CAP, 47UF, 10V,AXL,TANTALM, .420",10%
62.2099.0104 2 EA C10, 34 CAP, .1UF, 50V,SIP,CERAMIC, .100",10%
64.4011.0002 1 EA U3 CRYSTAL OSCILLATOR, 25MHZ
64.4012.0001 1 EA U6 CRYSTAL OSCILLATOR, 32MHZ
66.4503.0001 1 EA RY1 RELAY, 4PDT, 2A, 5VDC, PC. MNT, SEALED
