4-48
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
PCB Assy,
VL4
Universal Control (UCB) (continued)
24.9628.0073
PART NO. QTY REF DES DESCRIPTION
80.2513.0005 1 EA Q1 TRANSISTOR, MPSA05 NPN 60V 500MA TO92
82.4306.4001 1 EA D12 DIODE, RECTIFIER, 1N4001 50V 1A
82.4310.5817 1 EA D10 DIODE, RECTIFIER, 1N5817 20V 1A
82.4312.0105 8 EA D1.8 DIODE, FAST, MUR105/110 50V 1A
82.5301.5908 1 EA D13 DIODE, ZENER TS , 1N5908 5V 5W
82.5302.4148 1 EA D9 DIODE, ULTRAFAST, 1N4148 100V 10MA
82.5315.2835 3 EA D11, 14, 15 DIODE, SCHOTTKY , 5082.2835 8V 10MA
84.0068.0012 2 EA U16, 27 IC, MC68HC000P12 MICROPROCESSOR (HCMOS)
84.4105.0001 1 EA U37 IC, HD.6409.9 MANCHESTER ENCODER
84.4107.0002 6 EA U17.20, 30, 31 IC, UPD43256C.10L 32KX8 STAT RAM
84.4109.0002 2 EA U13, 14 IC, HD63B40P PROG.TIMER MODULE (CMOS)
84.4118.0001 1 EA U15 IC, MC68440P.8 DUAL DIR.MEM.ACCESS CTRLR
84.4129.0001 2 EA U46, 62 IC, 74F521 8.BIT MAGNITUDE COMPARATOR
84.4130.0001 1 EA U36 IC, 74HC04 HEX INVERTER
84.4131.0001 2 EA U41, 67 IC, 74HC05 HEX INVERTER W/OPENCOLLECTOR
84.4132.0001 1 EA U35 IC, 74HC08 QUAD 2.INPUT AND GATE
84.4133.0001 1 EA U54 IC, 74HC138 3.TO.8 DECODER
84.4134.0001 2 EA U8, 11 IC, 74HC14 HEX INV. SCHMIDT TRIGGER
84.4137.0001 1 EA U50 IC, 74HC164 8.BIT SHIFT REG.SER.IN/P.OUT
84.4139.0001 2 EA U45, 61 IC, 74HC191 UP/DOWN COUNTER
84.4140.0001 6 EA U9, 34, 55, 57, 58, 71 IC, 74HC244 OCTAL TRISTATE BUFFER
84.4141.0001 1 EA U72 IC, 74HC273 OCTAL D FLIP FLOP
84.4143.0001 1 EA U7 IC, 74HC4040 12.STAGE BINARY COUNTER
84.4145.0001 2 EA U38, 69 IC, 74HC74 DUAL D FLIP FLOP
84.4148.0001 1 EA U65 IC, 74LS148N 8.TO.3 PRIORITY ENCODER
84.4199.0001 2 EA U59, 60 IC, 74HC245 OCTAL BUS XCVR W/3.ST.OUTPUT
84.4200.0001 2 EA U32, 70 IC, 74HC125 QUAD BUFFER 3.STATE
84.7407.0157 2 EA U53, 68 IC, 74HC157 QUAD 2.TO.1 MULTIPLEXER
84.7407.0174 1 EA U33 IC, 74HC174 HEX D.FF W/CLR
84.7407.0573 2 EA U42, 43 IC, 74HC573 DIG CMOS OCT XPARENT (VL4)
84.7408.0004 1 EA U44 IC, 74AC04 HEX INVERTER
84.7408.0032 2 EA U52, 73 IC, 74AC32 QUAD 2.INPUT OR GATE
84.7408.0074 1 EA U4 IC, 74AC74 DUAL D FLIP FLOP
84.7408.0163 1 EA U5 IC, 74AC163 4BIT BIN COUNT SYNC RESET
84.7408.0164 1 EA U47 IC, 74AC164 8.BIT SHIFT REGISTER
84.7408.0251 1 EA U48 IC, 74AC251, DIGITAL MULTIPLXR
84.8201.0901 2 EA U28, 29 IC, MK68901N.5 MFP (VL4)
85.5105.0001 1 EA U1 IC, 75107B DUAL LINE RECEIVER
85.5106.0001 1 EA U2 IC, 75112 DUAL LINE DRIVER
85.5114.1210 1 EA U10 IC, DS1210 NON.VOLATILE CONTROLLER
