C
HAPTER
4. I
LLUSTRATED
P
ARTS
B
REAKDOWN
4-57
02.9628.0010 CONFIDENTIAL
7-Oct-97
4.2.3.20 PCB Assy, APS+ Control (
VL4
)
24.9628.0023
NO. PART NO. QTY REF DES DESCRIPTION
1 11.9628.0024 1 EA PCB, APS + CONTROL BOARD
2 50.2108.0001 3 EA XU3, 4, 5 SOCKET, IC PRECI.DIP 8 PIN
3 50.2110.0002 1 EA XU2 SOCKET, IC PRECI.DIP 10PIN
4 50.2714.0001 1 EA XU6 SOCKET, 14PIN DIP
5 50.2718.0001 1 EA XU1 SOCKET, 18PIN DIP
6 51.5003.0001 6 EA AP: Q201, D201, QA.QD SOCKET, TO-3 PC/HEATSINK
7 51.5011.0002 5 EA AP: LED1.5 MOUNTING PAD, LED
8 52.6243.0001 1 EA P2 CONN PLUG, MNLOK 6POS
9 52.6246.0002 1 EA P1 CONN, 64PIN TYPE C RT W/MFBL PIN
10 52.8256.0001 6 EA CONTACT SOCKET, MNLOK TIN
11 52.8244.0002 2 EA TO L INE FILTER FASTON RECEPT FLAG,.250 16-14AWG
(LOOSE)
12 52.8271.0002 1 EA CHASSIS GROUND FASTON RECEPT, 16-14AWG (LOOSE)
13 52.8283.0002 1 EA TP:GND TERM, SWAGE MT.TURRET (VL4)
14 53.2003.0001 3 EA AP: Q10, 11, 12 NUT, 4-40, KEP ZINC PLATED
15 53.6529.0001 1 EA AP: T1 CLIP, MOUNTING, DRIVE
16 53.6596.0001 3 EA AP: Q10, 11, 12 SCREW, 4-40X5/16"PPZ
17 55.2186.0001 7 EA CABLE TIE, SMALL .10X4"
18 55.6609.0003 1 EA UNDER U2 WASHER, NYLON .375OD .256ID, .032TH
19 55.6690.0001 1 EA AP: U2 PAD, MNTG. IC/DISCRETE COMPON 10PIN
20 55.9628.0001 1 EA GROMMET, 3/8"ID X7/8"ODX7/16"THICK
21 68.4507.0001 2 EA P/O T1 CORE, DRIVE
22 68.4521.0001 1 EA T2 TRANSFORMER, 400HZ, 1PRI/4SEC
23 68.9628.0023 1 EA T1 TRANSFORMER, APS+ VL4
24 73.7006.0001 6 IN WIRE, 16AWG STRND BLACK
25 73.7007.0001 6 IN WIRE, 16AWG STRND WHITE
26 73.7008.0001 6 IN WIRE, 16AWG STRND GREEN
27 73.7010.0001 6 IN WIRE, 16AWG 300V 80C GRY STRND UL1061
28 73.7012.0001 6 IN WIRE, 16AWG STRND RED
29 73.7013.0001 6 IN WIRE, 16AWG STRND BLUE
30 73.7016.0001 6 IN WIRE, 16AWG STRND WHITE/BLACK STRIPE
31 73.7053.0001 6 IN WIRE, 16AWG RED/BLACK STRIP
32 73.7042.0001 6 IN WIRE, 16AWG 300V 80C YEL STRND UL1061
33 74.1006.0003 1 EA TS1 THERMOSTAT, 205 DEGREES (VL4 APS+)
60.1420.1203 3 EA R3, 7, 20 RES, 1/4W 5% 1.2K CF
60.1420.1503 2 EA R9, 22 RES, 1/4W 5% 1.5K CF
60.1420.2204 3 EA R14, 15, 18 RES, 1/4W 5% 2.2K CF
60.1420.3302 1 EA R28 RES, 1/4W 5% 33K CF
60.1420.8203 1 EA R35 RES, 1/4W 5% 8.2K CF
60.1421.2202 1 EA R44 RES, 1/4W 5% 220 OHM CF
60.1421.4702 1 EA R31 RES, 1/4W 5% 47K CF
60.1422.1001 4 EA R4, 16, 29, 42 RES, 1/4W 5% 1K CF
60.1422.2202 1 EA R51 RES, 1/4W 5% 22K CF
60.1423.1803 1 EA R19 RES, 1/4W 5% 1.8K CF
60.1424.1005 17 EA R1, 2, 5, 6, 8, 10.12, 21,
23.25, 27, 32, 39, 40, 43
RES, 1/4W 5% 10K CF
