4-58
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
PCB Assy, APS+ Control (
VL4
) (continued)
24.9628.0023
PART NO. QTY REF DES DESCRIPTION
60.1425.1003 1 EA R38 RES, 1/4W 5% 100 OHMS CF
60.1425.5603 2 EA R13, 37 RES, 1/4W 5% 560 OHM CF
60.1426.1003 2 EA R26, 41 RES, 1/4W 5% 100K CF
60.1426.3904 1 EA R17 RES, 1/4W 5% 39K CF
60.1429.3303 2 EA R30, 34 RES, 1/4W 5% 330 CF
60.1431.1007 1 EA R36 RES, 1/4W 5% 10 OHM
60.3430.0047 4 EA R45.48 RES, 1W 5% 4.7OHM MET OXIDE
60.3430.1005 2 EA R49, 50 RES, 1W 5% 100K MET OXIDE
60.3530.1002 1 EA R33 RES, 1W 5% 100 OHM MF FLAME.PROOF
60.7442.1007 1 EA R53 RES, 5W 5% 10 OHMS WW
62.2002.0101 2 EA C3, 9 CAP, 100PF,1000V,RAD,DIPMICA, .234", 5%
62.2005.0001 3 EA C6, 7, 11 CAP, .01UF, 630V,RAD,POLYEST, .400",10%
62.2012.0104 1 EA C15 CAP, .1UF, 400V,RAD,POLYEST, .580",10%
62.2016.0104 3 EA C1, 2, 8 CAP, .1UF, 100V,RAD,POLYEST, .300",10%
62.2027.0475 2 EA C27, 28 CAP, 4.7UF, 35V,RAD,TANTALM, .125",10%
62.2042.0105 12 EA C4, 17.26, 31 CAP, 1UF, 35V,RAD,TANTALM, .125",10%
62.2043.0107 1 EA C29 CAP, 100UF, 25V,AXL,ALUMNUM, .630",20%
62.2047.0001 1 EA C13 CAP, .001UF,1000V,RAD,CERAMIC, .250",20%
62.2047.0022 1 EA CDS CAP,.0022UF,1000V,AXL,CERAMIC, .295", 5%
62.2049.0105 1 EA C12 CAP, 1UF, 400V,AXL,POLYPRO,1.500",10%
62.2083.0108 1 EA C10 CAP, 1000UF, 35V,AXL,ALUMNUM,1.240",20%
62.2087.0220 1 EA C5 CAP, .22UF, 100V,RAD,POLYEST, .400",10%
62.3000.0033 2 EA C14, 16 CAP, .033UF,1000V,RAD,POLYPRO, .400",10%
63.2012.0001 1 EA TR1 POT, 10K,LIN, 1TRN, HORIZ MNT, 10%
80.1512.0112 1 EA Q10 TRANSISTOR, TIP112 NPN 100V 2A TO220
80.1513.0117 2 EA Q11, 12 TRANSISTOR, TIP117 PNP 100V 2A TO220
80.2512.0113 1 EA Q9 TRANSISTOR, IRFD113 NCH 60V 800mA DIP4
80.2513.0005 7 EA Q1.7 TRANSISTOR, MPSA05 NPN 60V 500mA TO92
80.2513.0055 1 EA Q8 TRANSISTOR, MPSA55 PNP 60V 500mA TO92
82.4304.0856 1 EA D11 DIODE, FAST, MR856 600V 3A
82.4307.4002 1 EA DIODE, RECTIFIER, 1N4002 100V 1A
82.4312.0105 3 EA D8.10 DIODE, FAST, MUR105/110 50V 1A
82.4317.5819 7 EA D1.7 DIODE, RECTIFIER, 1N5819 40V 1A
82.5301.6303 2 EA Z3, 4 DIODE, ZENER TS ,1.5KE200 200V 5W
82.5304.4742 2 EA Z1, 2 DIODE, ZENER , 1N4742 12V 1W
83.3102.0001 1 EA U3 IC, LF442 DUAL JFET OP AMP
83.3109.0001 1 EA U6 IC, 14024 SEVEN STAGE RIPPLE COUNTER
83.3149.0002 1 EA U1 IC, SG3526N PULSE WIDTH MODULATOR
83.3152.0117 2 EA U4, 5 IC, INA117P, FET INPUT
83.3153.0100 1 EA U2 IC, MPY100 AM/AD632AH MULT.DIVIDER
88.8101.0001 2 EA LED1, 5 LED, RED HP
88.8102.0001 1 EA LED3 LED, YELLOW HP
88.8103.0001 2 EA LED2, 4 LED, GREEN HP
