Table 3-7. General Test Brief Summary Numbers
Test
Selection
Number Title
Display Character
for Error Codes
Commencement
1 Pan 1
2 Tilt 2
3 Beam 3
4 Edge 4
5 Intensity 5
6 Color 1 6
7 Color 2 7
8 Color 3 8
9 Null 9
10 Null A
11 Douser b
12 All mechanics synchronized C
13 All mechanics unsynchronized d
15 PSU test
20 PSU control
21 EOT sensors
22 Pan encoder
23 Tilt encoder
24 Form and function
25 Data loop-back
88 Thumbwheel
30 Enter program mode
31 to 39 Program mode exit, save,
and run program
40 Error history display
41 Clear error history
