3-16
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
Table 3-4. Manual Tests (continued)
Test Parameter Results
24 Form and
function
Display form and function switch in
two characters of hexadecimal.
25 Data loop-
back
9 External loop-back (relay
open and link required).
Loop-back successful = 0 (chasing)
8 Internal loop-back (relay
closed).
Transmit error = t
Receive error = r
88 Thumbwheel
test
Select 000 to exit test. display character last changed on
thumbwheel.
Table 3-5. Program Mode Selection
Test Parameter Results
30 Enter
program
mode
None Indication of test number for
selection, flashing number for
deselection, or "P" if invalid test
number.
31 Program
mode exit,
save and run
program
9 Synchronized mode. Error code displays during that
session.
8 Unsynchronized mode.
32
to
39
Same as
above.
Same as above. Same as above.
Table 3-6. Error History Selection
Test Parameter Results
40 Enter code
history
9 View error history since
clearing. Select scroll
speed.
Three character error codes are
displayed sequentially.
41 Clear error
code history.
Error code history is
cleared
Scrolling "parallel bars."
