Table 3-4. Manual Tests
Test Parameter Results
20 PSU control 9 Lamp on (latching). Scroll status of IPRES, PSOT,.
HOT, and SHORT.
8 Start (latching).
7 Lamp on and start and
intensity at 100 percent
(latching).
6 Lamp on and start and
intensity at 100 percent.
5 Lamp on and start and
intensity at 90 percent.
4 Lamp on and start and
intensity at 80 percent.
3 Lamp on and start and
intensity at 70 percent.
2 Lamp on and start and
intensity at 60 percent.
1 Lamp on and start and
intensity at 50 percent.
0 Douse (latching).
21 EOT sensors 8 Read color 3 sensor. Display character for closure,
flashing character for open.
7 Read color 2 sensor. Display character for closure,
flashing character for open.
6 Read color 1 sensor. Display character for closure,
flashing character for open.
5 Select intensity iris sensor. Display character for closure,
flashing character for open.
4 Select edge sensor. Display character for closure,
flashing character for open.
22 Pan encoder 9 Select MSD. Display digit.
Pan encoder 8 Select MSD. Display digit.
Pan encoder 7 Select MSD. Display digit.
Pan encoder 6 Select snapshot. Scroll digits.
23 Tilt encoder 9 Select MSD. Display digit.
8 Select MSD. Display digit.
7 Select MSD. Display digit.
6 Select snapshot. Scroll digits.
