Table 3-2. Mechanics Tests (continued)
Test Parameter Error Codes Results
13
All
mechanics
unsynchro
-nized
9 End stop Error codes as for all
other tests.
8 End stop
7 Speed 1
6 Speed 2
5 Speed 3
4 Speed 4
3 Speed 5
2 Speed 6
1 Speed 7
0 Speed 8
Table 3-3. PSU Tests (Simultaneous by Default)
Test Parameter Results
15 PSU test 9 Lamp on F01 IPRES at quiescent
8 Lamp on and start and
intensity at 100 percent
F03 HOT at quiescent
7 Lamp on and start and
intensity at 90 percent
F91 IPRES with lamp on
signal only
6 Lamp on and start and
intensity at 80 percent
F92 PSOT with lamp on signal
only.
5 Lamp on and start and
intensity at 70 percent
F93 HOT with lamp on signal
only.
4 Lamp on and start and
intensity at 65 percent
F94 SHORT with lamp on
signal only.
3 Lamp on and start and
intensity at 60 percent
FA2 PSOT while striking.
2 Lamp on and start and
intensity at 55 percent
FA3 HOT while striking.
1 Lamp on and start and
intensity at 50 percent
FA4 SHORT while striking.
0 Douse F82 to F12 PSOT while bulb struck.
F83 to F13 HOT while bulb struck.
F84 to F14 SHORT while bulb
struck.
F85 to F15 No IPRES while bulb
struck.
