VARILITE VL4 - Page 59

C
HAPTER
3. M
AINTENANCE
P
ROCEDURES
3-13
02.9628.0010 CONFIDENTIAL
7-Oct-97
Table 3-2. Mechanics Tests (continued)
Test Parameter Error Codes Results
Color 3 7 Speed 1 813 Backlash too large. Indicate backlash value
(half steps in
hexadecimal).
6 Speed 2 814 Sensor not hit, motion
impeded, sensor
permanently high
5 Speed 3 815 Sensor permanently
low.
4 Speed 4
3 Speed 5
2 Speed 6
1 Speed 7
0 Speed 8
9 Gobo 1 Null
10 Gobo 2 Null
11 Douser 9 End stop
8 End stop
7 Speed 1
6 Speed 2
5 Speed 3
4 Speed 4
3 Speed 5
2 Speed 6
1 Speed 7
0 Speed 8
12
All
mechanics
synchro-
nized
9 End stop Error codes as for all
other tests.
8 End stop
7 Speed 1
6 Speed 2
5 Speed 3
4 Speed 4
3 Speed 5
2 Speed 6
1 Speed 7
0 Speed 8
