VARILITE VL4 - Page 58

3-12
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
Table 3-2. Mechanics Tests (continued)
Test Parameter Error Codes Results
Intensity 1 Speed 7
0 Speed 8
6 Color 1 9 End stop 611 Sensor hit too early,
motion impeded.
8 End stop 612 Backlash too small (0).
7 Speed 1 613 Backlash too large. Indicate backlash value
(half steps in
hexadecimal).
6 Speed 2 614 Sensor not hit, motion
impeded, sensor
permanently high
5 Speed 3 615 Sensor permanently
low.
4 Speed 4
3 Speed 5
2 Speed 6
1 Speed 7
0 Speed 8
7 Color 2 9 End stop 711 Sensor hit too early,
motion impeded.
8 End stop 712 Backlash too small (0).
7 Speed 1 713 Backlash too large. Indicate backlash value
(half steps in
hexadecimal).
6 Speed 2 714 Sensor not hit, motion
impeded, sensor
permanently high
5 Speed 3 715 Sensor permanently
low.
4 Speed 4
3 Speed 5
2 Speed 6
1 Speed 7
0 Speed 8
8 Color 3 9 End stop 811 Sensor hit too early,
motion impeded.
8 End stop 812 Backlash too small (0).
