Description
Required tool
42. Tighten mounting screws adequately
Allen Wrench
3mm
43. Tighten clamp coupling screw with 1.1 Nm
Allen torque wrench
2mm
Install
valve
into
system
44. Reinstall valve into vacuum system
according to chapter «Installation».
