Installation, Operating & Maintenance Instructions
Series 615 DN 40 (I.D. 1½”), DeviceNet
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel +41 81 771 61 61 Fax +41 81 771 48 30 CH@vatvalve.com www.vatvalve.com
12. Place and reassemble the controller
panel (see steps 5…2)
13. Tighten the LOGIC connector screw with
1 Nm
(see step 4)
14. Tighten panel screws with 1.1Nm (see
step 2)
15. In case of replacement Interface board,
adjust the «NODE ADDRESS» and
«DATA RATE» on new Interface board
that you wrote down on step 1.
