Vacuum Packaging Machine VC999 K7
Description of the machine
Page 20/121 Art.-No. 592.016 2008-11-26
3.3 Technical data
3.3.1 Dimensions
Fig. 3/4
A Operator position B Bag waste suction unit (VC999 K7A)
Vacuum chamber
Max. product height (standard), without filling plate 250 mm
Length 890 mm
Width (sealing bar distance) 630 mm
Sealing bar height (adjustable) 40 or 80 mm
Length 2 x 870 mm
3.3.2 Weight
Machine without pump approx. 850 kg
Weight of rotary slide vacuum pump (300) approx. 220 kg
Weight of roots vacuum pump (W500) approx. 110 kg
