44
10. If you are replacing the printer cable, carefully pull out the printer cable, and then place the printhead so
that the printer cable port is facing directly up. Insert the new printer cable connector in to the port.
Note: Do not press against the port on the printhead unless the port is supported from behind. This
could cause the port to break off of the printhead.
11. Thread the printer cable wires underneath the printhead bar.
12. Slide the printhead into place.
13. Slide the printhead bar all the way to the right, and then push up on the printhead bar lock. This locks
the printhead bar in place.
14. Turn the printhead release lever all the way to the right, and then continue to the following section.
