Vertiv NetSure 8200 Series Installation Manual

Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
100
Figure 68: Installing Load Lug Adapter Plates into Distribution Only Bays (cont’d from previous page, cont’d on
next page)
NOTE THAT 1-POLE 218 CIRCUIT BREAKERS
DO NOT REQUIRE LOAD LUG ADAPTER PLATES
2-Position
Lug Adapter Kit
P/N 529132
3-Position
Lug Adapter Kit
P/N 529131
4-Position
Lug Adapter Kit
P/N 534420
1-Position Devices
(Load Busbars with NO
Lug Adapters Installed)
