Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
Installing Power/Distribution Bay Load Return Lug Extension Busbar Assembly, P/N
514543 (if furnished)
Tools and Material Required to Install the Busbar Assembly
a) 9/16" Wrench (for 3/8" Hardware)
b) Cross-Blade Screwdriver
c) Anti-Oxidation Compound
d) Torque Wrench
Installation Procedure
DANGER! Before performing this procedure, ensure that the power/distribution bay is COMPLETELY
DISCONNECTED from all power sources.
NOTE! Apply electrical anti-oxidation compound to mating surfaces of busbars before connecting
together.
1. Assemble the busbar kit to the top of the bays as shown in Figure 46 through Figure 51. Refer to
Figure 52 and Figure 53 for assembled views. Note that this busbar kit requires "External Top-Mount
Ground (Load Return) Busbar Assembly" P/N 514688, 514689, 514690, or 514691. This busbar kit
attaches to the P/N 514688, 514689, 514690, and 514691 busbar kits.
To Next Page
