Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
5. Remove the rear lower cover panel from each PDSC. This cover panel will be re-installed after all
mounting and electrical connection procedures have been completed. To do so: Remove the screws
and ground washers securing the cover panel. Remove the cover panel.
6. Remove the rear upper cover panel from each PDSC. This cover panel will be re-installed after all
mounting and electrical connection procedures have been completed.. To do so: Loosen the screws
securing the cover panel. Lift the cover panel until the screw heads clear the keyhole slots. Remove the
cover panel.
7. Remove the plug-button located on the left side (towards the front) of each PDSC, except the end
PDSC. This opening is provided for data communications cable routing between bays.
Placing and Securing the Bay(s) and PDSCs
1. Place bay(s) and PDSC(s) in position. Note that PDSCs are placed to the left (as viewed from the front)
of each bay. Note that clearance holes for 1/4” bolts are provided in the side rails of each bay and PDSC.
These holes are for bolting the bays and PDSCs together.
2. Level bay(s) and PDSC(s) as required, using leveling feet in base plate. Adjust leveling feet so that all
bays and PDSCs are even at top, and bolt holes in the side of each bay and PDSC line up with holes in
the adjacent cabinet(s).
3. Bolt all bays and PDSCs together. Use 1/4” hardware, five places per pair of cabinets. Use a ground
washer in two locations with the 1/4" hardware bolting two cabinets together.
NOTE! A ground washer is an internal-external tooth, dish-type lock washer. When installing ground
washers, ensure that the ground washer is oriented so that the teeth dig into the paint on the metal part
the ground washer is secured to (concave side faces the metal part).
4. Install shims between bottom of each bay and the floor as required to distribute floor loading.
5. Secure Power/Distribution Bay(s) and PDSC(s) to floor using fastening hardware per site requirements.
Installing Side Cover Panels on Right-Most End Bay
1. If the outside side of the right-most end bay does not have side cover panels, install them now (two per
side). Note that ground washers are used with each screw securing the side cover panels.
a) Install the rear-most side cover panel as follows: Insert tabs at front of cover panel into slots in
bay. Pivot cover panel into position against side of bay. Install the previously removed screws and
ground washers into cover panel from rear of bay.
b) Install the front-most side cover panel as follows: Open the bay's front door. Insert tabs at rear
of cover panel into slots in bay. Pivot cover panel into position against side of bay. Install the
previously removed screws and ground washers into cover panel from front of bay.
Placing and Securing List 103, 104, 105, 113, 114, and 115 Power Only Bays
• Refer to Figure 1 through Figure 18 as this procedure is performed. Figure 1 provides a floor hole
drilling pattern.
• Bays are typically placed next to each other and bolted together. Refer to “General Requirements” on
page 14, for bay line-up recommendations.
