INSTALLATION ACCEPTANCE CHECKLIST
Provided below is an Installation Acceptance Checklist. This checklist helps ensure proper installation and
initial operation of the system. As the procedures presented in this document are completed, check the
appropriate box on this list. If the procedure is not required to be performed for your installation site, also
check the box in this list to indicate that the procedure was read. When installation is done, ensure that each
block in this list has been checked. Some of these procedures may have been factory performed for you.
NOTE! The system is not powered up until the end of this checklist.
NOTE! Some of these procedures may have been performed at the factory for you.
Placing the Bays and Installing Internal/External Busbars
Bays (and PDSC if furnished) Bolted Together (if required) and Mounted to Floor
Bay-to-Bay Busbar Links Installed (if required)
PDSC (if furnished) AC Input Connectors Connected to Power/Distribution Bay
External Top-Mount Busbar Assemblies Installed (if furnished)
Installing Distribution Devices
Distribution Fuses and Circuit Breakers Installed
Distribution Lug Adapter Plates Installed
Making Switch and Jumper Settings
Factory Switch Settings on IB2 Board Verified
Factory Switch Settings on EIB Board Verified
Jumper and Switch Settings on SM-DUE Board Set
Jumper Setting on Distribution Bus Monitoring Circuit Cards Set
Making Electrical Connections
Bay-to-Bay Interconnections Made
Distribution Only Bay BAT RTN Connection to System Monitoring and Control Section Made
External Alarm, Reference, Monitoring, and Control Connections Made
Bay Frame Grounding Connections Made
Load Connections Made
AC Input and AC Input Ground Connections Made
Battery Connections Made
All Shields and Cover Panels in Re-Installed
