Vertiv | NetSure8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
142
Customer Connections to SM-DUE (if required)
General
Each secondary power/distribution bay and secondary power only bay contains a secondary control shelf. The
secondary control shelf contains an SM-DUE. The SM-DUE is used to input external monitoring information to
the NCU controller. Customer connections are provided for the following:
SM-DUE Input Power Voltage (19 VDC to 60 VDC)
+5 VDC Power Supply Output for Connection to External Hall Devices
Ten (10) input blocks with each providing the following monitoring inputs:
- One (1) Load Bus Voltage (0 VDC to 60 VDC) per input block
- One (1) Load Fuse Alarm (Bus- base of 0 VDC, >10 VDC alarm, <10 VDC normal) per input block
- One (1) Programmable Analog Input, can be set to accept one (1) of the following inputs per input
block:
10 mV DC to 50 mV DC Load Shunt
General-Purpose Current Transducer
General-Purpose Voltage Transducer
1 uA/K Temperature Sensor
NOTE!
Only the SM DUE designated as SMDUE1 and SMDUE2 via the addressing switches can have
temperature probes connected to them.
CAN Bus Port
Refer to the following procedures and make connections to the SM-DUE as required. Refer to Figure 82 for
SM-DUE location. Refer to Figure 87 for SM-DUE connector locations. See also “Switch Settings on SM-DUE
on page 114 and Jumper Settings on SM-DUE” on page 115.
