Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
126
Connector Locations on Secondary Power/Distribution Bay and Secondary Power Only Bay Control Shelf
Refer to Figure 82 for a connector location illustration.
Figure 82: Connector Locations – Secondary Power/Distribution Bay and Secondary Power Only Bay Control
Shelf
Control Shelf
Secondary Power Only Bay
Secondary Power/ Distribution Bay Similar
Front door removed in illustration for clarity only.
SM-DUE
CAN PortCAN Port
Front
Secondary Bay Control Shelf
