Local Area Network (LAN) Ethernet Port Connection (IB4 Board)
NOTE!
DO NOT connect your Local Area Network (LAN) to the NCU front panel Ethernet port.
The Local Area Network (LAN) cable is connected to the IB4 board. The IB4 board is mounted inside the
primary power/distribution bay or primary power only bay control shelf. Refer to Figure 83 for Ethernet Port
connector location.
Default Ethernet Port Parameters (IB4 Board)
IPv4
IP Address: 192.168.1.2
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.1.1
IPv6
IPv6 Address: 20fa:fffd:fffc:fffb:fffa:fff9:fff8:fff7
IPv6 Prefix: 0
IPv6 Gateway: 20fa:1:fffe:ffff:fffe:fffd:ffff:fffe
Procedure
1. An RJ-45 10BaseT jack is provided on the IB4 board for connection into a customer's network. This jack
has a standard Ethernet pin configuration scheme, twisted pair. Refer to Figure 83 for location and
Table 4 for pin outs. Use shielded Ethernet cable (grounded at both ends). Note that the IB4 board’s
RJ-45 jack is connected to chassis ground. Refer to the NCU controller Instructions (UM1M830BNA) for
operational details.
WARNING! The intra-building port(s) of the equipment or subassembly is suitable for connection to
intra-building or unexposed wiring or cabling only. The intra-building port(s) of the equipment or
subassembly MUST NOT be metallically connected to the interfaces that connect to the OSP or its
wiring. These interfaces are designed for use as intra-building interfaces only (Type 2 or Type 4 ports as
described in GR-1089-CORE, Issue 4) and require isolation from the exposed OSP cabling. The addition
of Primary Protectors is not sufficient protection in order to connect these interfaces metallically to OSP
wiring.
The intra-building port (RJ-45) of the equipment or subassembly must use shielded intra-building
cabling/wiring that is grounded at both ends.
Table 4:
RJ-45 Ethernet Port Pin Configuration
To Next Page
