Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
PLACING THE BAYS AND INSTALLING
INTERNAL/EXTERNAL BUSBARS
General Requirements
• The installer should be familiar with the installation requirements and techniques to be used in securing
the bay(s) to the floor.
• This product is intended only for installation in a Restricted Access Location on or above a non-
combustible surface.
• This product is intended for installation in Network Telecommunication Facilities (CO, vault, hut, or other
environmentally controlled electronic equipment enclosure).
• This product is intended to be connected to the common bonding network in a Network
Telecommunication Facility (CO, vault, hut, or other environmentally controlled electronic equipment
enclosure).
• Front and rear access is required for installation.
• Typical industry standards recommended minimum aisle space clearance is 2' 6" for the front of the
bay(s) and 2' for the rear of the bay(s). See also next paragraph.
• Rectifier ventilating openings must not be blocked and temperature of air entering rectifiers must not
exceed rated operating ambient temperature range found in System Application Guide SAG582140000.
Distance from rear of a power/distribution or power only bay to a wall or other solid structure must not
be less than 6 inches. This assures proper airflow through the rectifiers.
• The system consists of from 1 to 8 bays, depending upon your power requirements. All bays that are
designed to be bussed together must be placed in a line adjacent to each other, with no space between
bays. It is recommended to place the primary power/distribution bay or primary power only bay on the
far right or far left end of the bay line-up, and to expand the system to the left or right of the primary
power/distribution bay or primary power only bay. This allows simple cable connections between bays.
The primary power/distribution bay or primary power only bay may be placed in the middle of the bay
line-up, expanding the system to the left and right of the primary power/distribution bay or primary
power only bay. In this configuration, bay-to-bay cabling MUST start with the primary power/distribution
bay or primary power only bay, then each secondary power/distribution bay or secondary power only
bay and distribution only bays are daisy-chained into the cabling string.
Placing and Securing List 101 and List 111 Power/Distribution Bays (without PDSC)
NOTE! If you are installing List 102 and List 112 bays (with List 130, 131, or 132 PDSC), skip this
procedure and refer to “Placing and Securing List 102 and List 112 Power/Distribution Bays (with PDSC)"
starting on page 16.
• PDSC = AC Input 'Power Distribution Service Cabinet'.
• Refer to Figure 1 through Figure 18 as this procedure is performed. Figure 1 provides a floor hole
drilling pattern.
• Bays are typically placed next to each other and bolted together. Refer to “General Requirements” on
page 14, for bay line-up recommendations.
