Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
90
Installing Distribution Only Bay External Top-Mount Ground (Load Return) Extension
Busbar Assembly; P/N 528780 (if furnished)
Tools and Material Required to Install the Busbar Assembly
a) 9/16" Wrench (for 3/8" Hardware)
b) 15/16" Wrench (for 5/8" Hardware)
c) Cross-Blade Screwdriver
d) Anti-Oxidation Compound
e) Torque Wrench
Installation Procedure
DANGER! Before performing this procedure, ensure that the power/distribution bay is COMPLETELY
DISCONNECTED from all power sources.
NOTE! Apply electrical anti-oxidation compound to mating surfaces of busbars before connecting
together.
1. Assemble the busbar kit to the top of the bays as shown in Figure 63 and Figure 64.
