Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
124
External Alarm, Reference, and Control Connections
Connector Locations on Inside of Primary Power/Distribution Bay and Primary Power Only Bay Front
Door
Refer to Figure 80 for a connector location illustration.
Figure 80: Connector Locations – Primary Power/Distribution Bay and Primary Power Only Bay Front Door
Front Door (Inside View)
(Shield Removed
for Clarity)
Front Door (Inside View)
Primary Power/Distribution Bay,
Primary Power Only Bay
Front Door
Mounted Display
Front Door Mounted
Interface Asembly
HDMI*
Micro-USB
HDMI*
USB-B*
DC Power
Ethernet*
(to NCU)
USB*
* Factory Connection
Front Door Mounted
Interface Asembly
Micro-USB Cable
Connector Location
