Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
INSTALLING THE RECTIFIERS
Install rectifiers from top to bottom, starting with the top most mounting position.
The rectifier weighs approximately 40 lbs.
Rectifiers can be inserted or removed with power applied (hot swappable).
Procedure
1. Remove the blank panel from the rectifier mounting position. Save this panel. The panel must be re-
installed if a rectifier is removed.
NOTE! In the next step, a safety latch is present on the left-hand (as viewed from the front) side panel
of each rectifier. The latch is designed to prevent the rectifier from inadvertently being removed
completely from the bay once it has been installed. It should not be necessary to depress the safety
latch release when installing the rectifier.
2. Install the rectifier into the bay by sliding it evenly into its mounting position. Secure the rectifier to the
bay by tightening the captive fasteners on the rectifier.
3. Perform steps 1) and 2) for each rectifier to be installed.
