Vertiv | NetSure8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
94
6. Install Load Lug Adapter plates as required. Refer to Figure 68 for location and the numbering scheme
for the load lug mounting locations. Refer to Figure 69 through Figure 70 for load lug adapter selection
and installation details. Note that 1-pole devices do not require load lug adapter plates. Note that
Bullet Nose-Type devices CANNOT be used in Distribution Only Bays.
Installing TPL Fuses
Refer to Figure 71.
Procedure
1. Remove the fuseholder portion from the mounted fuseholder body by grasping its handle and pulling it
straight out. Install the TPL fuse into the fuseholder portion. Secure the fuse with the flat washer, lock
washer, and nut provided. Recommended torque is 168 in-lbs. When done, push the fuseholder portion
securely back into the mounted fuseholder body.
2. Ensure an alarm fuse is installed in the GMT-type fuseholder located adjacent to the TPL fuseholder.
The alarm fuse should be a Bussmann GMT 18/100 ampere alarm fuse. Vertiv P/N 248610301.
3. Ensure a safety fuse cover is installed on the GMT alarm fuse. Vertiv P/N 248898700.
Installing TLS/TPS Fuses
Refer to Figure 71 and Figure 72.
Procedure
1. Orient the Bullet Nose-Type Fuseholder over its mounting position and firmly press to seat the bullet-
type connectors.
2. Remove the fuseholder portion from the mounted fuseholder body by pulling it straight out. Install the
TLS/TPS fuse into the fuseholder. When done, push the fuseholder portion back into the mounted
fuseholder body.
3. Ensure an alarm fuse is installed in the GMT-type fuseholder provided on the mounted fuseholder body.
The alarm fuse should be a Bussmann GMT 18/100 ampere alarm fuse. Vertiv P/N 248610301.
4. Ensure a safety fuse cover is installed on the GMT alarm fuse. Vertiv P/N 248898700.
Installing Bullet Nose-Type Circuit Breakers
Refer to Figure 71 and Figure 72.
Power/Distribution Bay
1. Orient the circuit breaker over its mounting position with the ON position at top and firmly press to seat
the bullet-type connectors.
Distribution Only Bay
Note that Bullet Nose-Type devices CANNOT be used in Distribution Only Bays.
