Installing Power/Distribution Bay External Top-Mount Horizontal Battery Input Busbar
Assembly, P/N 554873 (if furnished)
Tools and Material Required to Install the Busbar Assembly
a) 9/16" Wrench (for 3/8" Hardware)
b) 15/16" Wrench (for 5/8" Hardware)
c) Channel Locks
d) Anti-Oxidation Compound
e) Torque Wrench
Installation Procedure
DANGER! Before performing this procedure, ensure that the Power/Distribution Bay is COMPLETELY
DISCONNECTED from all power sources.
NOTE! Apply electrical anti-oxidation compound to mating surfaces of busbars before connecting
together.
Assemble the busbar kit to the top of the bays as shown in Figure 23 through Figure 30. Refer to Figure 30
for an assembled view.
