Vertiv NetSure 8200 Series Installation Manual

Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
79
Installing Power/Distribution Bay External Top-Mount Vertical Battery Input Busbar
Assembly, P/N 554874 (if furnished)
Tools and Material Required to Install the Busbar Assembly
a) 9/16" Wrench (for 3/8" Hardware)
b) 15/16" Wrench (for 5/8" Hardware)
c) Channel Locks
d) Anti-Oxidation Compound
e) Torque Wrench
Installation Procedure
DANGER! Before performing this procedure, ensure that the power/distribution bay is COMPLETELY
DISCONNECTED from all power sources.
NOTE! Apply electrical anti-oxidation compound to mating surfaces of busbars before connecting
together.
1. Assemble the busbar kit to the top of the bays as shown in Figure 54 through Figure 61.
