b) Install the front-most side cover panel as follows: Open the bay's front door. Insert tabs at rear
of cover panel into slots in bay. Pivot cover panel into position against side of bay. Install the
previously removed screws and ground washers into cover panel from front of bay.
Placing and Securing List 102 and List 112 Power/Distribution Bays (with PDSC)
NOTE! If you are installing List 101 and List 111 Bays (without List 130, 131, or 132 PDSC), skip this
procedure and refer to “Placing and Securing List 101 and List 111 Power/Distribution Bays (without
PDSC)" starting on page 14.
• PDSC = AC Input 'Power Distribution Service Cabinet'.
• Refer to Figure 1 through Figure 18 as this procedure is performed. Figure 2 provides a floor hole
drilling pattern.
• Bays are typically placed next to each other and bolted together. Refer to “General Requirements” on
page 14, for bay line-up recommendations. PDSCs are located to the left (as viewed from the front) of
each power/distribution bay.
Procedure
Preparing the Bays and PDSCs
1. Remove all front rectifier mounting position blank cover panels from each power/distribution bay to
provide access to bay's floor mounting holes and leveling feet. Cover panels will be re-installed in empty
rectifier mounting positions after all rectifiers are installed. To do so: Remove the screws and ground
washers securing the cover panel. Remove the cover panel.
2. Remove the three rear cover panels from each power/distribution bay. These cover panels will be re-
installed after all mounting and electrical connection procedures have been completed.
To do so:
Top
Panel: Loosen the screws securing the cover panel. Lift the cover panel until the screw heads clear the
keyhole slots. Remove the cover panel. Lower Panels: Remove the screws and ground washers
securing the panel. Remove the panel.
3. Remove the side cover panels from each power/distribution bay (two per side) as follows, if equipped.
Note that you may leave the side cover panels on the "outside side" of the right-most (as viewed from
the front) end bay.
a) Remove the rear-most side cover panel as follows: Remove the screws and ground washers
securing the side cover panel. Screws are accessible from the rear of the bay through holes in the
side channels. After removing screws, pivot rear edge of cover panel outward, then slide cover
panel toward rear of bay to disengage tabs at the front of the cover panel from slots in the bay.
b) Remove the front-most side cover panel as follows: Open the bay's front door. Remove the
screws and ground washers securing the side cover panel. Screws are accessible from the front of
the bay through holes in the side channels. After removing screws, pivot front edge of cover panel
outward, then slide cover panel toward front of bay to disengage tabs at the rear of the cover panel
from slots in the bay.
4. Remove the front cover panel from each PDSC. This cover panel will be re-installed after all mounting
and electrical connection procedures have been completed. To do so: Remove the screws and ground
washers securing the cover panel. Remove the cover panel.
