Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
77
Figure 52: Power/Distribution Bay Load Return Lug Extension Busbar Assembly (P/N 514543) Assembled
Views
Assembled View P/N 514543
P/N 514543
P/N 514688
or 514689
P/N 554873
P/N 514543
P/N 514690
or 514691
P/N 554873
Busbar Assembly Assembled on Top of Bays (List 101 and 111 Bays)
Busbar Assembly Assembled on Top of Bays (List 102 and 112 Bays w/ List 130 or 131 PDSC)
