Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
140
Table 9: Relay Outputs (Factory Default) – EIB
Programmable Relay Output
EIB
Pin No.
Alarms Assigned to this Relay (Default)
EIB-1 DO1
NC J8-1
Not Used
COM
J8-3
NO J8-5
EIB-1 DO2
NC
J8-2
Test / Equalize COM J8-4
NO
J8-6
EIB-1 DO3
NC J9-1
Rectifier Alarms
COM
J9-3
NO J9-5
EIB-1 DO4
NC
J9-2
Multi-Rectifier Fail COM J9-4
NO
J9-6
EIB-1 DO5
NC J7-2
OB Summary
COM
J7-4
NO J7-6
NOTE! The relays energize during an alarm condition, closing the contacts between the C and NO
terminals, and opening the contacts between the C and NC terminals.
NOTE! The relays may be preprogrammed for specific functions. Refer to the configuration drawing
(C-drawing) supplied with your system for your system’s specific configuration.
