Vertiv NetSure 8200 Series Installation Manual

Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
152
Figure 93: Distribution Only Bay Frame Grounding Connection Locations
1/4" clearance holes
on 5/8” centers are
provided for installation
of customer provided
two-hole lug.
1/4" clearance holes
on 5/8” centers are
provided for installation
of customer provided
two-hole lug.
Top View
Distribution Only Bay
Recm. Torque
1/4” Hardware
using Belleville
Lock Washer
60 in-lbs.
